Garmin GT56UHD-TH Transducer - Thru-Hull 12-Pin

Introducing the Garmin GT56UHD-TH Thru-Hull Transducer, a versatile all-in-one transducer that offers ultimate functionality for your fishing needs. With Ultra High-Definition ClearVü and SideVü scanning sonars, high wide CHIRP traditional sonar, and more, this transducer allows you to spend more time catching fish.

Experience unparalleled clarity with the Ultra High-Definition scanning sonar that allows you to see everything below and around your boat. The high wide CHIRP traditional sonar ensures excellent target separation, providing you with a clear view of the underwater environment. No matter what depth you're fishing, the multiple sonar frequencies have got you covered.

With the Garmin GT56UHD-TH Transducer, you can see targets and structure in bright, vivid color, making it easier than ever to distinguish between different elements. Whether you prefer transom, trolling motor, or thru-hull mounting, this transducer offers the flexibility to be mounted your way.

Features:

• Ultra High-Definition scanning sonar for clear imaging of structure and fish
• High wide CHIRP traditional sonar for exceptional target separation
• Multiple sonar frequencies for all fishing depths
• Bright and vivid color palettes for easy target and structure identification
• Versatile mounting options for transom, trolling motor, or thru-hull

Specifications:

• Transducer Cable Length: 25 ft
• Transducer Frequency: Traditional High-wide CHIRP (150-240 kHz); ClearVü/SideVü 455 kHz (425-485 kHz), 800 kHz (790-850 kHz), 1000 kHz (940-1100)
• Transducer Power: Traditional 350 W; ClearVü/SideVü 500 W
• Transducer Beamwidth: Traditional CHIRP: 24-16; ClearVü 0.52 x 52 at 1000 kHz, 0.64 x 35 at 800 kHz, 1.1 x 52 at 455 kHz; SideVü 0.52 x 52 at 1000 kHz, 0.64 x 35 at 800 kHz, 1.1 x 52 at 455 kHz
• Transducer Maximum Depth: Traditional: 800 ft freshwater; ClearVü: 400 ft; SideVü: 500 ft
• Transducer Depth/Speed/Temperature: Depth and temperature
• Transducer Number of Pins: 12
• Transducer Supported Deadrise/Transom Angles: 0&deg-70&deg degree transom (GT56UHD-TM)

What's in the Box:

• GT56UHD-TH transducer
• Stainless steel stem
• Fairing block
• Isolation plate and bushings
• Extension cable
• Mounting hardware
• Documentation

Learn More:

• Ultra High-Definition (Wikipedia)
• CHIRP (Wikipedia)
• Sonar (Wikipedia)

Specifications

Product: Garmin 010-02732-10 Gt56Uhd-Th Transducer Thru -Hull 12-Pin

Brand: Garmin

Model: 010-02732-10

Additional Shipping Information:

Shipping Weight: 9.20 lb

Shipping Height: 4.00 in

Shipping Width: 7.00 in

Shipping Length: 16.00 in
